Model

1000

Usage

Suitable for multi-stranding core wire kinds of high frequency communication cable , data cable

computer cable, power cable etc for cabling, with center taping and side taping synchronize to finish.

Inlet wire

0.6-5.0mm core wire

Finished wire

Max 20mm

Cabling pitch

20-800mm

Taping pitch

3-60mm

Cantilever  Rotation

20-400RPM

Taping Rotation

20-2000RPM

Line Speed

1-60mm/min

Binder bobbin

￠180X20

Taping bobbin

￠500X40

Pay off bobbin

400-630

Take up bobbin

1000X750
